Kúpos szorítós, perem nélküli laposszíjtárcsa

Kúpos szorítós, perem nélküli laposszíjtárcsa
Ajánlatkérés
Cikkszám: perem nélküli laposszíjtárcsa
Elérhetőség: Raktáron
Ajánlatkérés

Leírás és Paraméterek

Öntöttvas laposszíjtárcsa kúpos szorítós kivitelben. Perem nélküli, foszfátozott felületű. Hordósított felületű, így a tárcsa önműködően középen tartja a szíjat

Laposszíj tárcsa katalógus

Cikkszám Tárcsa átmérő(mm) Tárcsa szélesség(mm) Szorító típusa
ltar_63mm_32mm 63 mm 32 mm 1108
ltar_63mm_50mm 63 mm 50 mm 1108
ltar_67mm_32mm 67 mm 32 mm 1108
ltar_71mm_32mm 71 mm 32 mm 1210
ltar_75mm_32mm 75 mm 32 mm 1210
ltar_80mm_32mm 80 mm 32 mm 1210
ltar_80mm_50mm 80 mm 50 mm 1210
ltar_80mm_80mm 80 mm 80 mm 1615
ltar_85mm_32mm 85 mm 32 mm 1210
ltar_85mm_50mm 85 mm 50 mm 1210
ltar_90mm_100mm 90 mm 100 mm 1615
ltar_90mm_32mm 90 mm 32 mm 1610
ltar_90mm_50mm 90 mm 50 mm 1610
ltar_90mm_80mm 90 mm 80 mm 1615
ltar_95mm_32mm 95 mm 32 mm 1610
ltar_95mm_50mm 95 mm 50 mm 1610
ltar_100mm_32mm 100 mm 32 mm 1615
ltar_100mm_50mm 100 mm 50 mm 1610
ltar_100mm_80mm 100 mm 80 mm 1610
ltar_100mm_100mm 100 mm 100 mm 1615
ltar_106mm_32mm 106 mm 32 mm 1610
ltar_106mm_50mm 106 mm 50 mm 1610
ltar_112mm_32mm 112 mm 32 mm 1610
ltar_112mm_50mm 112 mm 50 mm 2012
ltar_118mm_32mm 118 mm 32 mm 1610
ltar_118mm_50mm 118 mm 50 mm 2012
ltar_125mm_100mm 125 mm 100 mm 2012
ltar_125mm_125mm 125 mm 125 mm 2517
ltar_125mm_32mm 125 mm 32 mm 2517
ltar_125mm_50mm 125 mm 50 mm 1610
ltar_125mm_80mm 125 mm 80 mm 2012
ltar_132mm_32mm 132 mm 32 mm 2517
ltar_132mm_50mm 132 mm 50 mm 2012
ltar_132mm_80mm 132 mm 80 mm 2012
ltar_140mm_100mm 140 mm 100 mm 3020
ltar_140mm_125mm 140 mm 125 mm 3030
ltar_140mm_32mm 140 mm 32 mm 2012
ltar_140mm_50mm 140 mm 50 mm 2012
ltar_140mm_80mm 140 mm 80 mm 2517
ltar_150mm_100mm 150 mm 100 mm 3020
ltar_150mm_125mm 150 mm 125 mm 3030
ltar_150mm_160mm 150 mm 160 mm 3030
ltar_150mm_32mm 150 mm 32 mm 2012
ltar_150mm_50mm 150 mm 50 mm 2012
ltar_150mm_80mm 150 mm 80 mm 2517
ltar_160mm_100mm 160 mm 100 mm 3020
ltar_160mm_125mm 160 mm 125 mm 3030
ltar_160mm_160mm 160 mm 160 mm 3030
ltar_160mm_32mm 160 mm 32 mm 2012
ltar_160mm_50mm 160 mm 50 mm 2012
ltar_160mm_80mm 160 mm 80 mm 2517
ltar_170mm_32mm 170 mm 32 mm 2012
ltar_170mm_50mm 170 mm 50 mm 2517
ltar_170mm_80mm 170 mm 80 mm 2517
ltar_180mm_100mm 180 mm 100 mm 3020
ltar_180mm_125mm 180 mm 125 mm 3030
ltar_180mm_160mm 180 mm 160 mm 3030
ltar_180mm_32mm 180 mm 32 mm 2012
ltar_180mm_50mm 180 mm 50 mm 2517
ltar_180mm_80mm 180 mm 80 mm 2517
ltar_190mm_32mm 190 mm 32 mm 2517
ltar_190mm_50mm 190 mm 50 mm 2517
ltar_190mm_80mm 190 mm 80 mm 2517
ltar_200mm_100mm 200 mm 100 mm 3020
ltar_200mm_125mm 200 mm 125 mm 3030
ltar_200mm_160mm 200 mm 160 mm 3030
ltar_200mm_32mm 200 mm 32 mm 2517
ltar_200mm_50mm 200 mm 50 mm 2517
ltar_200mm_80mm 200 mm 80 mm 2517
ltar_212mm_100mm 212 mm 100 mm 3020
ltar_212mm_32mm 212 mm 32 mm 2517
ltar_212mm_50mm 212 mm 50 mm 2517
ltar_212mm_80mm 212 mm 80 mm 3020
ltar_224mm_100mm 224 mm 100 mm 3020
ltar_224mm_125mm 224 mm 125 mm 3030
ltar_224mm_160mm 224 mm 160 mm 3030
ltar_224mm_32mm 224 mm 32 mm 2517
ltar_224mm_50mm 224 mm 50 mm 2517
ltar_224mm_80mm 224 mm 80 mm 3020
ltar_236mm_100mm 236 mm 100 mm 3020
ltar_236mm_125mm 236 mm 125 mm 3030
ltar_236mm_50mm 236 mm 50 mm 2517
ltar_236mm_80mm 236 mm 80 mm 3020
ltar_250mm_100mm 250 mm 100 mm 3020
ltar_250mm_125mm 250 mm 125 mm 3030
ltar_250mm_160mm 250 mm 160 mm 3030
ltar_250mm_32mm 250 mm 32 mm 2517
ltar_250mm_50mm 250 mm 50 mm 2517
ltar_250mm_80mm 250 mm 80 mm 3020
ltar_265mm_32mm 265 mm 32 mm 2517
ltar_265mm_50mm 265 mm 50 mm 2517
ltar_265mm_80mm 265 mm 80 mm 3020
ltar_280mm_100mm 280 mm 100 mm 3020
ltar_280mm_125mm 280 mm 125 mm 3030
ltar_280mm_160mm 280 mm 160 mm 3535
ltar_280mm_200mm 280 mm 200 mm 4040
ltar_280mm_32mm 280 mm 32 mm 2517
ltar_280mm_50mm 280 mm 50 mm 2517
ltar_280mm_80mm 280 mm 80 mm 3020
ltar_300mm_100mm 300 mm 100 mm 3020
ltar_300mm_125mm 300 mm 125 mm 3030
ltar_300mm_32mm 300 mm 32 mm 2517
ltar_300mm_50mm 300 mm 50 mm 3020
ltar_300mm_80mm 300 mm 80 mm 3020
ltar_315mm_100mm 315 mm 100 mm 3020
ltar_315mm_125mm 315 mm 125 mm 3030
ltar_315mm_160mm 315 mm 160 mm 3535
ltar_315mm_200mm 315 mm 200 mm 4040
ltar_315mm_32mm 315 mm 32 mm 2517
ltar_315mm_50mm 315 mm 50 mm 3020
ltar_315mm_80mm 315 mm 80 mm 3020
ltar_335mm_100mm 335 mm 100 mm 3020
ltar_335mm_125mm 335 mm 125 mm 3535
ltar_335mm_160mm 335 mm 160 mm 3535
ltar_335mm_50mm 335 mm 50 mm 3020
ltar_355mm_100mm 355 mm 100 mm 3535
ltar_355mm_125mm 355 mm 125 mm 3535
ltar_355mm_160mm 355 mm 160 mm 3535
ltar_355mm_200mm 355 mm 200 mm 4040
ltar_355mm_32mm 355 mm 32 mm 2517
ltar_355mm_50mm 355 mm 50 mm 3020
ltar_355mm_80mm 355 mm 80 mm 3030
ltar_400mm_100mm 400 mm 100 mm 3535
ltar_400mm_125mm 400 mm 125 mm 3535
ltar_400mm_160mm 400 mm 160 mm 3535
ltar_400mm_200mm 400 mm 200 mm 4040
ltar_400mm_32mm 400 mm 32 mm 2517
ltar_400mm_50mm 400 mm 50 mm 3020
ltar_400mm_80mm 400 mm 80 mm 3535
ltar_450mm_100mm 450 mm 100 mm 3535
ltar_450mm_125mm 450 mm 125 mm 3535
ltar_450mm_160mm 450 mm 160 mm 3535
ltar_450mm_200mm 450 mm 200 mm 4040
ltar_450mm_32mm 450 mm 32 mm 2517
ltar_450mm_50mm 450 mm 50 mm 3020
ltar_450mm_80mm 450 mm 80 mm 3535
ltar_500mm_100mm 500 mm 100 mm 4040
ltar_500mm_125mm 500 mm 125 mm 4040
ltar_500mm_160mm 500 mm 160 mm 4040
ltar_500mm_200mm 500 mm 200 mm 4545
ltar_500mm_32mm 500 mm 32 mm 3020
ltar_500mm_50mm 500 mm 50 mm 3535
ltar_500mm_80mm 500 mm 80 mm 4040
ltar_560mm_100mm 560 mm 100 mm 4040
ltar_560mm_125mm 560 mm 125 mm 4040
ltar_560mm_160mm 560 mm 160 mm 4040
ltar_560mm_200mm 560 mm 200 mm 4545
ltar_560mm_50mm 560 mm 50 mm 3535
ltar_560mm_80mm 560 mm 80 mm 4040
ltar_630mm_100mm 630 mm 100 mm 4545
ltar_630mm_125mm 630 mm 125 mm 4545
ltar_630mm_160mm 630 mm 160 mm 4545
ltar_630mm_200mm 630 mm 200 mm 5050
ltar_630mm_32mm 630 mm 32 mm 3020
ltar_630mm_50mm 630 mm 50 mm 3020
ltar_630mm_80mm 630 mm 80 mm 4545
Anyaga öntöttvas
Kivitele kúpos szorítós
Felületkezelés foszfátozott
Szabvány szám DIN 111 / ISO 100
Egyéb minden tárcsa futófelülete hordósított
